• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Type	Super Gripbelt V-Belts
Belt Section	B
Height	0.44
Pitch Length	106.8
Material	Neoprene
Operating Temperature [Max] ºF	140 °F
Efficiency (%)	0.95
Operating Temperature [Max] ºC	60 °C
Product Type	Wrapped Belt
Outside Length/Diameter (in)	108 in
Width (in)	0.69 in
Outside Diameter (in)	108 in
Standards met	ARPM IP-20
Belt Series	Classical Series - Inch
Construction Type	Wrapped
Number of Ribs	1
Section Size	B
Reinforcing cord material	Polyester
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Operating Temperature Range	-32 to +140 °F

General Specifications

UPC	662289169498
Weight	1.29 LB
Packaged Length	6.40 IN
Packaged Width	16.30 IN
Packaged Height	1.95 IN
HTC	4010.39.1000
Country of Origin	Mexico
