• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Wrench Torque (in-lb)	192
Product Type	Split Taper Bushing
Cap Screws (Size)	5/16 x 1 1/4
Compatible Bore Size [Max] (mm)	25 mm
Bore Size (mm)	25 mm
Length Through Bore (mm)	49.2125 mm
Model Name	B_Bushing-Type1_Master
Outside Diameter (mm)	93.6625 mm
Material	Sintered Steel or Ductile Iron
Total Length (mm)	49.2125 mm
Outside Diameter (in)	3.6875 in
Bushing Type	B
Keyseat (mm)	8 x 3.5 mm
Total Length (in)	1.9375 in
Cap Screws (No.)	3
Bore Type	Metric
Flange Thickness	0.5
Barrel Diameter (Small End)	2.5567
Screw Length	1.25
Thread Size	5/16-18
Bolt Circle Diameter (in)	3.125
Barrel Diameter (Large End)	2.625
Flange Type	Solid Flange
Includes	Cap Screws and Ext. Key
Mounting Type	Conventional

General Specifications

UPC	662289393381
Weight	3.02 LB
Packaged Length	4.40 IN
Packaged Width	4.50 IN
Packaged Height	2.50 IN
