• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bushing Type	B
Keyseat	1/2 x 1/4
Product Type	Split Taper Bushing
Model Name	B_Bushing-Type2_Master
Total Length (in)	1.9375 in
Outside Diameter (in)	3.6875 in
Length Through Bore (in)	1.9375 in
Compatible Bore Size [Max] (in)	2 in
Wrench Torque (in-lb)	192
Material	Sintered Steel or Ductile Iron
Bore Size (in)	2 in
Cap Screws (Size)	5/16 x 1 1/4
Bore Type	Inch
Cap Screws (No.)	3
Screw Length	1.25
Includes	Cap Screws & Spcl Key
Barrel Diameter (Small End)	2.5567
Flange Thickness	0.5
Barrel Diameter (Large End)	2.625
Thread Size	5/16-18
Mounting Type	Conventional
Bolt Circle Diameter (in)	3.125
Flange Type	Solid Flange

General Specifications

UPC	662289038480
Weight	1.96 LB
Packaged Length	4.40 IN
Packaged Width	4.50 IN
Packaged Height	2.50 IN
