• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Size (in)	2.4375 in
Length Through Bore (in)	1.9375 in
Model Name	B_Bushing-Type2_Master
Product Type	Split Taper Bushing
Total Length (in)	1.9375 in
Bushing Type	B
Compatible Bore Size [Max] (in)	2.4375 in
Wrench Torque (in-lb)	192
Outside Diameter (in)	3.6875 in
Cap Screws (Size)	5/16 x 1 1/4
Material	Sintered Steel or Ductile Iron
Keyseat	5/8 x 5/16
Bore Type	Inch
Cap Screws (No.)	3

General Specifications

UPC	662289038541
Weight	1.66 LB
Packaged Length	4.30 IN
Packaged Width	4.40 IN
Packaged Height	2.50 IN
