• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Cap Screws (Size)	5/16 x 1 1/4
Total Length (in)	1.9375 in
Product Type	Split Taper Bushing
Compatible Bore Size [Max] (in)	1.4375 in
Wrench Torque (in-lb)	192
Bushing Type	B
Model Name	B_Bushing-Type1_Master
Length Through Bore (in)	1.9375 in
Material	Sintered Steel or Ductile Iron
Bore Size (in)	1.4375 in
Outside Diameter (in)	3.6875 in
Keyseat	3/8 x 3/16
Cap Screws (No.)	3
Bore Type	Inch
Includes	Cap Screws and Ext. Key
Bolt Circle Diameter (in)	3.125
Screw Length	1.25
Flange Thickness	0.5
Flange Type	Solid Flange
Mounting Type	Conventional
Thread Size	5/16-18
Barrel Diameter (Small End)	2.5567
Barrel Diameter (Large End)	2.625

General Specifications

UPC	662289038411
Weight	2.61 LB
Packaged Length	4.40 IN
Packaged Width	4.50 IN
Packaged Height	2.50 IN
