• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Size (in)	1.75 in
Bushing Type	B
Material	Sintered Steel or Ductile Iron
Length Through Bore (in)	1.9375 in
Compatible Bore Size [Max] (in)	1.75 in
Model Name	B_Bushing-Type1_Master
Wrench Torque (in-lb)	192
Cap Screws (Size)	5/16 x 1 1/4
Outside Diameter (in)	3.6875 in
Total Length (in)	1.9375 in
Product Type	Split Taper Bushing
Keyseat	3/8 x 3/16
Cap Screws (No.)	3
Bore Type	Inch
Thread Size	5/16-18
Screw Length	1.25
Bolt Circle Diameter (in)	3.125
Includes	Cap Screws and Ext. Key
Barrel Diameter (Large End)	2.625
Flange Type	Solid Flange
Flange Thickness	0.5
Mounting Type	Conventional
Barrel Diameter (Small End)	2.5567

General Specifications

UPC	662289038367
Weight	2.21 LB
Packaged Length	4.40 IN
Packaged Width	4.50 IN
Packaged Height	2.50 IN
