• EPDM Material provides expanded operating temperature range to -60F degrees to 250F degrees which helps ensure long-life and reliable performance in the moste demanding climates and heat sensitive applications.
• Precision Molded Cogs - Provide more surface area for heat dissipation and increase belt flexibility. Cooler running means longer life. Browning Notched belts assure longer life when replacing existing Wrapped V-Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.
• Raw-Edge Sidewalls - Improved gripping contract with pulley sidewalls. Assures less vibration and Smoother , quieter performance. Notched belts provide higher horsepower than wrapped belts.

Technical Specifications

Pitch Length	145.3
Type	Gripnotch Notched V-Belts
Belt Section	AX
Material	EPDM
Outside Length/Diameter (in)	146.2 in
Outside Diameter (in)	146.2 in
Product Type	Notched Belt
Operating Temperature [Max] ºF	250 °F
Efficiency (%)	0.98
Operating Temperature [Max] ºC	121 °C
Belt Series	Gripnotch
Section Size	AX
Number of Ribs	1
Width (in)	0.5 in
Construction Type	Cogged
Height	0.3125
Reinforcing cord material	Nylon

General Specifications

UPC	662289359424
Weight	0.75 LB
Packaged Length	7.15 IN
Packaged Width	21.95 IN
Packaged Height	1.55 IN
HTC	4010.39.1000
Country of Origin	United States of America
