• Largest Selection of finished bore sheaves of any other manufacturer - Browning offers finished bore sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum (3L)	7.66
Warning	Do not use these "AK" sheaves with bores 1" and under with gripnotch belt ratings.
Model Name	AK_Sheave_Master2
Material	Cast Iron
Outside Diameter (in)	8.25 in
Number of Grooves	1
Pitch Diameter (A)	8.2
Bore (in)	1 in
Product Type	FHP - Finished Bore
Belt Section	4L or A, 3L
Bore Type	Finished with Keyway and SS
Pulley Construction	Spoked
Face Width (in)	0.75
Keyway Size	1/4 x 1/8
Overall Width (in)	1.53125
Set Screw Thread	5/16-18UNC-3AX3/8
Set Screw Tightening Torque (in-lb)	165

General Specifications

UPC	662289267057
Weight	5.14 LB
Packaged Length	8.40 IN
Packaged Width	8.50 IN
Packaged Height	1.60 IN
HTC	8483.50.9040
Country of Origin	Mexico
