• Largest Selection of finished bore sheaves of any other manufacturer - Browning offers finished bore sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	AK_Sheave_Master2
Number of Grooves	1
Outside Diameter (in)	8.25 in
Pitch Diameter (A)	8.2
Warning	Do not use these "AK" sheaves with bores 1" and under with gripnotch belt ratings.
Datum (3L)	7.66
Material	Cast Iron
Bore (in)	0.5 in
Belt Section	4L or A, 3L
Product Type	FHP - Finished Bore
Bore Type	Finished with Setscrew. No Keyway
Overall Width (in)	1.53125
Face Width (in)	0.75
Pulley Construction	Spoked
Set Screw Thread	5/16-18UNC-3AX3/8
Set Screw Tightening Torque (in-lb)	165

General Specifications

UPC	662289157075
Weight	5.49 LB
Packaged Length	8.40 IN
Packaged Width	8.50 IN
Packaged Height	1.60 IN
HTC	8483.50.9040
Country of Origin	Mexico
