• Largest Selection of finished bore sheaves of any other manufacturer - Browning offers finished bore sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	5.45 in
Pitch Diameter (A)	5.4
Material	Cast Iron
Number of Grooves	1
Datum (3L)	4.86
Model Name	AK_Sheave_Master2
Bore (in)	0.875 in
Belt Section	4L or A, 3L
Product Type	FHP - Finished Bore
Bore Type	Finished with Keyway and SS
Overall Width (in)	1.21875
Pulley Construction	Spoked
Keyway Size	.1875
Face Width (in)	0.75
Set Screw Tightening Torque (in-lb)	165
Set Screw Thread	5/16-18UNC-3AX3/8

General Specifications

UPC	662289116638
Weight	2.60 LB
Packaged Length	5.60 IN
Packaged Width	5.60 IN
Packaged Height	1.60 IN
HTC	8483.50.9040
Country of Origin	Mexico
