• Largest Selection of finished bore sheaves of any other manufacturer - Browning offers finished bore sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum (3L)	4.86
Pitch Diameter (A)	5.4
Outside Diameter (in)	5.45 in
Number of Grooves	1
Model Name	AK_Sheave_Master2
Material	Cast Iron
Bore (in)	1.1875 in
Product Type	FHP - Finished Bore
Belt Section	4L or A, 3L
Pitch Diameter (3L)	4.8600
Bore Type	Finished with Keyway and SS
Keyway Size	2.5 x .125
Pulley Construction	Spoke
Face Width (in)	0.75
Overall Width (in)	1.22
Number of Hubs	1
Set Screw Tightening Torque (in-lb)	165
Set Screw Thread	5/16-18UNC-3AX3/8

General Specifications

UPC	662289206711
Weight	1.67 LB
Packaged Length	5.70 IN
Packaged Width	5.80 IN
Packaged Height	1.40 IN
HTC	8483.50.9040
Country of Origin	Mexico
