• Largest Selection of finished bore sheaves of any other manufacturer - Browning offers finished bore sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	5.45 in
Number of Grooves	1
Pitch Diameter (A)	5.4
Datum (3L)	4.86
Model Name	AK_Sheave_Master2
Material	Cast Iron
Bore (in)	1.125 in
Belt Section	4L or A, 3L
Product Type	FHP - Finished Bore
Bore Type	Finished with Keyway and SS
Pulley Construction	Spoked
Overall Width (in)	1.21875
Face Width (in)	0.75
Keyway Size	.250
Set Screw Thread	5/16-18UNC-3AX3/8
Set Screw Tightening Torque (in-lb)	165

General Specifications

UPC	662289591039
Weight	2.49 LB
Packaged Length	5.60 IN
Packaged Width	5.70 IN
Packaged Height	1.40 IN
HTC	8483.50.9040
Country of Origin	Mexico
