• Largest Selection of finished bore sheaves of any other manufacturer - Browning offers finished bore sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (A)	4.9
Model Name	AK_Sheave_Master2
Material	Cast Iron
Outside Diameter (in)	4.95 in
Number of Grooves	1
Datum (3L)	4.36
Bore (in)	1 in
Belt Section	4L or A, 3L
Product Type	FHP - Finished Bore
Bore Type	Finished with Keyway and SS
Face Width (in)	0.75
Keyway Size	.250
Overall Width (in)	1.21875
Pulley Construction	Spoked
Set Screw Thread	5/16-18UNC-3AX3/8
Set Screw Tightening Torque (in-lb)	165

General Specifications

UPC	662289106561
Weight	2.36 LB
Packaged Length	5.60 IN
Packaged Width	5.60 IN
Packaged Height	1.40 IN
HTC	8483.50.9040
Country of Origin	Mexico
