• Largest Selection of H Bushed sheaves of any other manufacturer - Browning offers bushed sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (3L)	4.16
Type of Bore	Bushed
Number of Grooves	1
Pitch Diameter (A)	4.7
Datum Diameter (A)	4.5
Model Name	AKH_Sheave_Master
Material	Cast Iron
Outside Diameter (in)	4.75 in
Belt Section	4L or A, 3L
Outside Length (in)	1.5 in
Bore (Min) (in)	0.375 in
Product Type	FHP - Bushed
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Overall Width (in)	1.5
Bushing Bore Range	0.375 - 1.500
Face Width (in)	0.75

General Specifications

UPC	662289142071
Weight	2.33 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.31 IN
HTC	8483.50.9040
Country of Origin	Mexico
