• Largest Selection of H Bushed sheaves of any other manufacturer - Browning offers bushed sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	AKH_Sheave_Master
Pitch Diameter (A)	3.2
Datum Diameter (A)	3
Pitch Diameter (3L)	2.66
Type of Bore	Bushed
Number of Grooves	1
Material	Cast Iron
Bore (Min) (in)	0.375 in
Outside Length (in)	1.8125 in
Product Type	FHP - Bushed
Belt Section	4L or A, 3L
Outside Diameter (in)	3.25 in
Bore Type	Split Taper Bushed
Face Width (in)	0.75
Bushing Bore Range	0.375 - 1.500
Overall Width (in)	1.8125
Pulley Construction	Plain

General Specifications

UPC	662289251933
Weight	1.45 LB
Packaged Length	3.70 IN
Packaged Width	3.70 IN
Packaged Height	1.50 IN
HTC	8483.50.9040
Country of Origin	Mexico
