• Largest Selection of finished bore sheaves of any other manufacturer - Browning offers finished bore sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (A)	2.3
Number of Grooves	1
Model Name	AK_Sheave_Master1
Outside Diameter (in)	2.3 in
Material	Cast Iron
Warning	Do not use these "AK" sheaves with bores 1" and under with gripnotch belt ratings.
Datum (3L)	1.76
Bore (in)	0.625 in
Product Type	FHP - Finished Bore
Belt Section	4L or A, 3L
Bore Type	Finished with Keyway and SS
Pitch Diameter (3L)	1.7600
Keyway Size	.1875 x .0938
Pulley Construction	Solid
Face Width (in)	0.75
Overall Width (in)	1.23
Number of Hubs	1
Set Screw Thread	5/16-18UNC-3AX3/8
Set Screw Tightening Torque (in-lb)	165

General Specifications

UPC	662289196043
Weight	0.67 LB
Packaged Length	3.40 IN
Packaged Width	3.10 IN
Packaged Height	1.30 IN
HTC	8483.50.9040
Country of Origin	Mexico
