• Largest Selection of H Bushed sheaves of any other manufacturer - Browning offers bushed sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	AKH_Sheave_Master
Type of Bore	Bushed
Pitch Diameter (A)	14.2
Pitch Diameter (3L)	13.66
Material	Cast Iron
Number of Grooves	1
Datum Diameter (A)	14
Product Type	FHP - Bushed
Bore (Min) (in)	0.375 in
Outside Length (in)	1.5 in
Outside Diameter (in)	14.25 in
Belt Section	4L or A, 3L
Bore Type	Split Taper Bushed
Face Width (in)	0.75
Overall Width (in)	1.5
Bushing Bore Range	0.375 - 1.500
Pulley Construction	Plain

General Specifications

UPC	662289316106
Weight	8.30 LB
Packaged Length	14.31 IN
Packaged Width	14.31 IN
Packaged Height	1.56 IN
HTC	8483.50.9040
Country of Origin	Mexico
