• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Type	Super Gripbelt V-Belts
Height	0.34
Belt Section	A
Pitch Length	90.3
Material	Neoprene
Efficiency (%)	0.95
Outside Diameter (in)	91.22 in
Width (in)	0.54 in
Operating Temperature [Max] ºF	140 °F
Product Type	Wrapped Belt
Operating Temperature [Max] ºC	60 °C
Outside Length/Diameter (in)	91.22 in
Reinforcing cord material	Polyester
Section Size	A
Belt Series	Classical Series - Inch
Construction Type	Wrapped
Standards met	ARPM IP-20
Number of Ribs	1
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Operating Temperature Range	-32 to +140 °F

General Specifications

UPC	662289248568
Weight	0.66 LB
Packaged Length	6.45 IN
Packaged Width	16.50 IN
Packaged Height	1.40 IN
HTC	4010.34.3000
Country of Origin	Mexico
