• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Belt Section	A
Height	0.34
Pitch Length	87.3
Type	Super Gripbelt V-Belts
Material	Neoprene
Operating Temperature [Max] ºC	60 °C
Operating Temperature [Max] ºF	140 °F
Efficiency (%)	0.95
Outside Diameter (in)	88.22 in
Outside Length/Diameter (in)	88.22 in
Width (in)	0.54 in
Product Type	Wrapped Belt
Number of Ribs	1
Reinforcing cord material	Polyester
Standards met	ARPM IP-20
Belt Series	Classical Series - Inch
Construction Type	Wrapped
Section Size	A
Operating Temperature Range	-32 to +140 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3

General Specifications

UPC	662289308552
Weight	0.64 LB
Packaged Length	5.65 IN
Packaged Width	12.90 IN
Packaged Height	1.55 IN
HTC	4010.34.3000
Country of Origin	Mexico
