• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Height	0.34
Belt Section	A
Pitch Length	71.3
Type	Super Gripbelt V-Belts
Material	Neoprene
Operating Temperature [Max] ºF	140 °F
Outside Length/Diameter (in)	72.22 in
Width (in)	0.54 in
Efficiency (%)	0.95
Product Type	Wrapped Belt
Operating Temperature [Max] ºC	60 °C
Outside Diameter (in)	72.22 in
Number of Ribs	1
Section Size	A
Construction Type	Wrapped
Belt Series	Classical Series - Inch
Reinforcing cord material	Polyester
Standards met	ARPM IP-20
Operating Temperature Range	-32 to +140 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3

General Specifications

UPC	662289208395
Weight	0.54 LB
Packaged Length	10.30 IN
Packaged Width	5.65 IN
Packaged Height	1.65 IN
HTC	4010.34.3000
Country of Origin	Romania
