• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Type	Super Gripbelt V-Belts
Pitch Length	27.3
Height	0.34
Belt Section	A
Material	Neoprene
Product Type	Wrapped Belt
Width (in)	0.54 in
Operating Temperature [Max] ºC	60 °C
Outside Length/Diameter (in)	28.22 in
Outside Diameter (in)	28.22 in
Operating Temperature [Max] ºF	140 °F
Efficiency (%)	0.95
Standards met	ARPM IP-20
Number of Ribs	1
Reinforcing cord material	Polyester
Construction Type	Wrapped
Section Size	A
Belt Series	Classical Series - Inch
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Operating Temperature Range	-32 to +140 °F

General Specifications

UPC	662289247950
Weight	0.21 LB
Packaged Length	3.50 IN
Packaged Width	12.20 IN
Packaged Height	0.85 IN
HTC	4010.32.3000
Country of Origin	Mexico
