• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Height	0.3125
Pitch Length	159.3
Type	Super Gripbelt V-Belts
Belt Section	A
Material	Neoprene
Product Type	Wrapped Belt
Outside Diameter (in)	160.22 in
Outside Length/Diameter (in)	160.22 in
Operating Temperature [Max] ºF	140 °F
Operating Temperature [Max] ºC	60 °C
Width (in)	0.5 in
Efficiency (%)	0.95
Section Size	A
Construction Type	Classic
Belt Series	Gripbelt

General Specifications

UPC	662289218738
Weight	1.09 LB
Packaged Length	7.60 IN
Packaged Width	23.55 IN
Packaged Height	1.75 IN
HTC	4010.39.1000
Country of Origin	Mexico
