• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Number of teeth	96
Bore Range	1/2 to 1 3/4
Width (mm)	19.05 mm
Product Type	Gearbelt Pulley
Material	Cast Iron
Bore Type	Bushed Bore
Outside Diameter (in)	11.429 in
Outside Diameter (mm)	290.2966 mm
Inside Diameter (in)	10.6875 in
Pitch Diameter (in)	11.459 in
Belt Section	L
Width (in)	0.75 in
Face Width	1
Overall Length (in)	2.28125 in
With Flanges	No Flanges
Length Through Bore	1.938
Hub Diameter (in)	3 in
Number of Hubs	1
Hub Projection	0.96925
Pulley Construction	Arm

General Specifications

UPC	662289143443
Weight	10.40 LB
Packaged Length	12.20 IN
Packaged Width	12.30 IN
Packaged Height	2.60 IN
HTC	8483.50.9080
Country of Origin	United States of America
