• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	1/2 to 2 15/16
Product Type	Gearbelt Pulley
Width (mm)	25.4 mm
Number of teeth	96
Material	Cast Iron
Bore Type	Bushed Bore
Width (in)	1 in
Inside Diameter (in)	14.125 in
Pitch Diameter (in)	15.279 in
Outside Diameter (mm)	386.715 mm
Outside Diameter (in)	15.225 in
Belt Section	H
Face Width	1.3125
Hub Diameter (in)	4.625 in
Pulley Construction	Arm
Overall Length (in)	2.3722 in
With Flanges	No Flanges
Number of Hubs	1
Length Through Bore	2
Hub Projection	1.062

General Specifications

UPC	662289354610
Weight	26.04 LB
Packaged Length	15.25 IN
Packaged Width	1.75 IN
Packaged Height	15.25 IN
HTC	8483.50.9080
Country of Origin	United States of America
