• Browning 358 Wrapped Belts are constructed of Neoprene material wrapped top and botttom; operating temperature range of -30F to 140F degrees.
• More horsepower in less space - Browning 358 Belts provide more horsepower in the same span than conventional ABC Belts. This enables you to reduce drive cost.
• Greater Horsepower allows for smaller drive sheaves - Using 358 Belts can allow for smaller drive components while still meeting the drive requirements , thus lowering the overall drive cost.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.

Technical Specifications

Belt Section	8V
Type	358 Gripbelt
Material	Neoprene
Operating Temperature [Max] ºC	60 °C
Efficiency (%)	0.95
Outside Length (in)	180 in
Outside Length/Diameter (in)	180 in
Product Type	Wrapped Belt
Operating Temperature [Max] ºF	140 °F
Section Size	8V
Reinforcing cord material	Synthetic Fiber
Width (in)	1 in
Height	0.9063
Pitch Length	180

General Specifications

UPC	662289297870
Weight	6.25 LB
Packaged Length	13.50 IN
Packaged Width	13.20 IN
Packaged Height	5.00 IN
HTC	4010.39.1000
Country of Origin	Mexico
