• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (5V)	9.65
Overall Length (in)	6.015625 in
Bushing Used	S1
Material	Cast Iron
Number of Grooves	8
Pulley Material	Cast Iron
Outside Diameter (in)	9.75 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore (Min) (in)	1.6875 in
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Face Width (in)	5.8125
Keyway Size	.750
Bushing Bore Range	1.6875 - 4.1875
Overall Width (in)	6

General Specifications

UPC	662289290819
Weight	53.00 LB
Packaged Length	9.75 IN
Packaged Width	9.75 IN
Packaged Height	6.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
