• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	8
Bushing Used	S1
Overall Length (in)	6.015625 in
Material	Cast Iron
Pitch Diameter (5V)	13.1
Outside Diameter (in)	13.2 in
Pulley Material	Cast Iron
Belt Section	5V
Product Type	Multiple Sheaves
Bore (Min) (in)	1.6875 in
Bore Type	Split Taper Bushed
Overall Width (in)	6
Keyway Size	.750
Pulley Construction	Spoked
Face Width (in)	5.8125
Bushing Bore Range	1.6875 - 4.1875

General Specifications

UPC	662289111107
Weight	79.00 LB
Packaged Length	13.20 IN
Packaged Width	13.20 IN
Packaged Height	6.00 IN
