• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	S1
Number of Grooves	8
Outside Diameter (in)	11.8 in
Material	Cast Iron
Pitch Diameter (5V)	11.7
Overall Length (in)	6.015625 in
Pulley Material	Cast Iron
Bore (Min) (in)	1.6875 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.750
Bushing Bore Range	1.6875 - 4.1875
Pulley Construction	Webbed
Face Width (in)	5.8125
Overall Width (in)	6

General Specifications

UPC	662289230990
Weight	85.00 LB
Packaged Length	11.80 IN
Packaged Width	11.80 IN
Packaged Height	6.00 IN
