• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Material	Cast Iron
Outside Diameter (in)	6.55 in
Datum Diameter (B)	6.2
Datum Diameter (A)	5.8
Number of Grooves	8
Overall Length (in)	6.25 in
Pitch Diameter (A)	6
Bushing Used	Q2
Pitch Diameter (B)	6.5
Belt Section	A, B
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Overall Width (in)	6.25
Face Width (in)	6.25
Pulley Construction	Webbed
Bushing Bore Range	1.000 - 2.625
Keyway Size	.500

General Specifications

UPC	662289104505
Weight	23.00 LB
Packaged Length	6.55 IN
Packaged Width	6.55 IN
Packaged Height	6.25 IN
