• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Number of teeth	84
Width (mm)	25.4 mm
Bore Range	3/8 to 1 1/2
Product Type	Gearbelt Pulley
Bore Type	Bushed Bore
Material	Cast Iron
Outside Diameter (mm)	253.9238 mm
Width (in)	1 in
Belt Section	L
Inside Diameter (in)	9.25 in
Outside Diameter (in)	9.997 in
Pitch Diameter (in)	10.027 in
Face Width	1.25
Pulley Construction	Arm
Length Through Bore	1.276
Overall Length (in)	1.65625 in
With Flanges	No Flanges

General Specifications

UPC	662289314492
Weight	8.24 LB
Packaged Length	10.30 IN
Packaged Width	10.30 IN
Packaged Height	2.40 IN
HTC	8483.50.9080
Country of Origin	United States of America
