• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	7
Material	Cast Iron
Datum Diameter (C)	8.6
Overall Length (in)	7.25 in
Pitch Diameter (C)	9
Outside Diameter (in)	9 in
Bushing Used	R2
Pulley Material	Cast Iron
Belt Section	C
Product Type	Multiple Sheaves
Bore (Min) (in)	1.375 in
Bore Type	Split Taper Bushed
Number of Hubs	1
Face Width (in)	7.25
Overall Width (in)	7.25
Bushing Bore Range	1.00 - 2.625
Pulley Construction	Web
Keyway Size	0.75

General Specifications

UPC	662289285877
Weight	52.92 LB
Packaged Length	9.38 IN
Packaged Width	5.00 IN
Packaged Height	9.38 IN
