• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (C)	16.4
Outside Diameter (in)	16.4 in
Material	Cast Iron
Datum Diameter (C)	16
Number of Grooves	7
Overall Length (in)	7.25 in
Pulley Material	Cast Iron
Bushing Used	R2
Bore (Min) (in)	1.375 in
Belt Section	C
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.750
Bushing Bore Range	1.375 - 3.625

General Specifications

UPC	662289156887
Weight	88.00 LB
Packaged Length	16.40 IN
Packaged Width	16.40 IN
Packaged Height	7.25 IN
