• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	R2
Datum Diameter (C)	10.6
Number of Grooves	7
Overall Length (in)	7.25 in
Pitch Diameter (C)	11
Outside Diameter (in)	11 in
Pulley Material	Cast Iron
Material	Cast Iron
Belt Section	C
Product Type	Multiple Sheaves
Bore (Min) (in)	1.375 in
Bore Type	Split Taper Bushed
Keyway Size	.750
Bushing Bore Range	1.375 - 3.625

General Specifications

UPC	662289311224
Weight	69.00 LB
Packaged Length	11.88 IN
Packaged Width	5.00 IN
Packaged Height	11.88 IN
HTC	8483.50.9040
Country of Origin	Mexico
