• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Model Name	GBPulley_Master6
Number of teeth	72
Bore Range	1/2 to 2 15/16
Width (mm)	25.4 mm
Product Type	Gearbelt Pulley
Bore Type	Bushed Bore
Material	Cast Iron
Outside Diameter (mm)	289.687 mm
Width (in)	1 in
Belt Section	H
Outside Diameter (in)	11.405 in
Inside Diameter (in)	10.375 in
Pitch Diameter (in)	11.459 in
Face Width	1.3125
With Flanges	No Flanges
Hub Projection	1.06025
Overall Length (in)	2.3722 in
Pulley Construction	Arm
Number of Hubs	1
Hub Diameter (in)	4.625 in
Length Through Bore	2

General Specifications

UPC	662289353699
Weight	17.78 LB
Packaged Length	11.88 IN
Packaged Width	1.75 IN
Packaged Height	11.88 IN
HTC	8483.50.9080
Country of Origin	United States of America
