• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Pitch Diameter (C)	10.2
Material	Cast Iron
Datum Diameter (C)	9.8
Model Name	6TC-L_Sheave_Master
Outside Diameter (in)	10.2 in
Number of Grooves	6
Bushing Used	Q2
Overall Length (in)	6.25 in
Belt Section	C
Product Type	Multiple Sheaves
Bore (Min) (in)	1 in
Bore Type	Split Taper Bushed
Keyway Size	.500
Bushing Bore Range	1.000 - 2.625

General Specifications

UPC	662289273430
Weight	41.50 LB
Packaged Length	10.50 IN
Packaged Width	10.50 IN
Packaged Height	6.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
