• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Pitch Diameter (C)	9.6
Overall Length (in)	6.25 in
Bushing Used	Q2
Outside Diameter (in)	9.6 in
Model Name	6TC-L_Sheave_Master
Pulley Material	Cast Iron
Number of Grooves	6
Datum Diameter (C)	9.2
Belt Section	C
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Number of Hubs	1
Overall Width (in)	6.25
Face Width (in)	6.25
Bushing Bore Range	1.000 - 2.625
Keyway Size	0.5
Pulley Construction	Web

General Specifications

UPC	662289193301
Weight	38.96 LB
Packaged Length	9.75 IN
Packaged Width	9.75 IN
Packaged Height	6.25 IN
