• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	Q2
Model Name	6TC-L_Sheave_Master
Overall Length (in)	6.25 in
Datum Diameter (C)	8.4
Pulley Material	Cast Iron
Outside Diameter (in)	8.8 in
Material	Cast Iron
Number of Grooves	6
Pitch Diameter (C)	8.8
Product Type	Multiple Sheaves
Belt Section	C
Bore (Min) (in)	1 in
Bore Type	Split Taper Bushed
Bushing Bore Range	1.000 - 2.625
Keyway Size	.500

General Specifications

UPC	662289310593
Weight	36.72 LB
Packaged Length	9.60 IN
Packaged Width	9.80 IN
Packaged Height	6.60 IN
HTC	8483.50.9040
Country of Origin	Mexico
