• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	6
Model Name	6TB-L_Sheave_Master
Bushing Used	Q2
Material	Cast Iron
Overall Length (in)	4.828125 in
Pulley Material	Cast Iron
Outside Diameter (in)	9.35 in
Pitch Diameter (B)	9.3
Pitch Diameter (A)	8.8
Datum Diameter (A)	8.6
Datum Diameter (B)	9
Bore (Min) (in)	1 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.500
Overall Width (in)	4.78125
Pulley Construction	Webbed
Bushing Bore Range	1.000 - 2.625
Face Width (in)	4.75

General Specifications

UPC	662289182183
Weight	33.46 LB
Packaged Length	9.75 IN
Packaged Width	9.75 IN
Packaged Height	4.75 IN
