• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	6TB-L_Sheave_Master
Bushing Used	Q2
Outside Diameter (in)	8.35 in
Material	Cast Iron
Pulley Material	Cast Iron
Overall Length (in)	4.828125 in
Number of Grooves	6
Pitch Diameter (A)	7.8
Pitch Diameter (B)	8.3
Datum Diameter (A)	7.6
Datum Diameter (B)	8
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Bushing Bore Range	1.000 - 2.625
Face Width (in)	4.75
Keyway Size	.500
Pulley Construction	Webbed
Overall Width (in)	4.78125

General Specifications

UPC	662289262083
Weight	27.08 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	4.75 IN
