• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	6
Outside Diameter (in)	7.15 in
Bushing Used	Q1
Pulley Material	Cast Iron
Model Name	6TB-M_Sheave_Master
Material	Cast Iron
Overall Length (in)	5.078125 in
Pitch Diameter (B)	7.1
Pitch Diameter (A)	6.6
Datum Diameter (B)	6.8
Datum Diameter (A)	6.4
Belt Section	A, B
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Bushing Bore Range	2.6875 - 2.6875
Overall Width (in)	5.03125
Keyway Size	.500
Face Width (in)	4.75

General Specifications

UPC	662289171941
Weight	20.73 LB
Packaged Length	8.10 IN
Packaged Width	8.10 IN
Packaged Height	6.50 IN
