• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (B)	5.6
Bushing Used	Q1
Material	Cast Iron
Pitch Diameter (A)	5.4
Pulley Material	Cast Iron
Overall Length (in)	5.078125 in
Pitch Diameter (B)	5.9
Datum Diameter (A)	5.2
Model Name	6TB-M_Sheave_Master
Outside Diameter (in)	5.95 in
Number of Grooves	6
Product Type	Multiple Sheaves
Belt Section	A, B
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Face Width (in)	4.75
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Webbed
Overall Width (in)	5.03125
Keyway Size	.500

General Specifications

UPC	662289101597
Weight	13.86 LB
Packaged Length	6.06 IN
Packaged Width	6.06 IN
Packaged Height	4.75 IN
