• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	6
Material	Cast Iron
Datum Diameter (A)	3.4
Pitch Diameter (B)	4.1
Pitch Diameter (A)	3.6
Pulley Material	Cast Iron
Datum Diameter (B)	3.8
Model Name	6TB-S_Sheave_Master
Overall Length (in)	5.578125 in
Bushing Used	P2
Outside Diameter (in)	4.15 in
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Keyway Size	.375
Bushing Bore Range	0.750 - 1.750

General Specifications

UPC	662289271184
Weight	7.56 LB
Packaged Length	5.19 IN
Packaged Width	5.19 IN
Packaged Height	4.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
