• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (A)	13.4
Overall Length (in)	4.828125 in
Model Name	6TB-L_Sheave_Master
Bushing Used	Q2
Outside Diameter (in)	13.95 in
Number of Grooves	6
Material	Cast Iron
Pulley Material	Cast Iron
Pitch Diameter (B)	13.9
Datum Diameter (B)	13.6
Datum Diameter (A)	13.2
Product Type	Multiple Sheaves
Belt Section	A, B
Bore (Min) (in)	1 in
Bore Type	Split Taper Bushed
Keyway Size	.500
Bushing Bore Range	1.000 - 2.625

General Specifications

UPC	662289182336
Weight	47.42 LB
Packaged Length	14.00 IN
Packaged Width	14.00 IN
Packaged Height	4.75 IN
