• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (5V)	14.9
Outside Diameter (in)	15 in
Number of Grooves	6
Pulley Material	Cast Iron
Bushing Used	S1
Material	Cast Iron
Overall Length (in)	5.328125 in
Bore (Min) (in)	1.6875 in
Product Type	Multiple Sheaves
Belt Section	5V
Bore Type	Split Taper Bushed
Pulley Construction	Spoked
Face Width (in)	4.4375
Keyway Size	.750
Overall Width (in)	5.3125
Bushing Bore Range	1.6875 - 4.1875

General Specifications

UPC	662289101252
Weight	69.25 LB
Packaged Length	15.75 IN
Packaged Width	15.75 IN
Packaged Height	4.75 IN
