• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Overall Length (in)	5.328125 in
Number of Grooves	6
Outside Diameter (in)	12.5 in
Pitch Diameter (5V)	12.4
Material	Cast Iron
Bushing Used	S1
Product Type	Multiple Sheaves
Bore (Min) (in)	1.6875 in
Belt Section	5V
Bore Type	Split Taper Bushed
Bushing Bore Range	1.6875 - 4.1875
Face Width (in)	4.4375
Overall Width (in)	5.3125
Pulley Construction	Spoked
Keyway Size	.750

General Specifications

UPC	662289101023
Weight	65.00 LB
Packaged Length	12.50 IN
Packaged Width	12.50 IN
Packaged Height	5.31 IN
