• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	8.5 in
Pulley Material	Cast Iron
Overall Length (in)	4.4375 in
Bushing Used	R1
Material	Cast Iron
Pitch Diameter (5V)	8.4
Number of Grooves	6
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Belt Section	5V
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Overall Width (in)	4.4375
Keyway Size	.750
Bushing Bore Range	1.125 - 3.750
Face Width (in)	4.4375

General Specifications

UPC	662289270644
Weight	27.45 LB
Packaged Length	9.10 IN
Packaged Width	9.10 IN
Packaged Height	5.50 IN
