• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	4.4375 in
Bushing Used	R1
Outside Diameter (in)	11.8 in
Pitch Diameter (5V)	11.7
Number of Grooves	6
Material	Cast Iron
Pulley Material	Cast Iron
Bore (Min) (in)	1.125 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Overall Width (in)	4.4375
Keyway Size	.750
Bushing Bore Range	1.125 - 3.750
Pulley Construction	Webbed
Face Width (in)	4.4375

General Specifications

UPC	662289180967
Weight	41.75 LB
Packaged Length	11.88 IN
Packaged Width	11.88 IN
Packaged Height	5.25 IN
