• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Pitch Diameter (5V)	7.4
Number of Grooves	6
Bushing Used	Q2
Material	Cast Iron
Outside Diameter (in)	7.5 in
Overall Length (in)	4.4375 in
Bore (Min) (in)	1 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Number of Hubs	1
Face Width (in)	4.4375
Pulley Construction	Web
Overall Width (in)	4.4375
Keyway Size	0.5
Bushing Bore Range	1.000 - 2.625

General Specifications

UPC	662289110513
Weight	28.36 LB
Packaged Length	7.88 IN
Packaged Width	7.88 IN
Packaged Height	4.75 IN
HTC	8483.50.9040
Country of Origin	Mexico
