• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	7.4 in
Datum Diameter (C)	7
Model Name	6C_LG_Sheavemaster
Bushing Used	SF
Number of Grooves	6
Pulley Material	Cast Iron
Pitch Diameter (C)	7.4
Material	Cast Iron
Belt Section	C
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.938

General Specifications

UPC	662289409884
Weight	23.44 LB
Packaged Length	7.88 IN
Packaged Width	7.88 IN
Packaged Height	6.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
