• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (C)	16.4
Outside Diameter (in)	16.4 in
Pulley Material	Cast Iron
Overall Length (in)	6.296875 in
Number of Grooves	6
Datum Diameter (C)	16
Material	Cast Iron
Bushing Used	R2
Product Type	Multiple Sheaves
Belt Section	C
Bore (Min) (in)	1.375 in
Bore Type	Split Taper Bushed
Bushing Bore Range	1.375 - 3.625
Keyway Size	.750

General Specifications

UPC	662289226856
Weight	77.00 LB
Packaged Length	16.40 IN
Packaged Width	16.40 IN
Packaged Height	6.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
